Ubiquiti PoE adapter (24V, 12W). Designed by Ubiquiti for BaseStation Equipment. Features earth grounding/ESD protection, power LED, and remote reset capability. Compatible with RouterBoard, Alix etc.
Technical specification:
| Output Voltage | 24VDC @0.5A |
| Input Voltage | 90-260VAC @47-63Hz |
| Input Current | 0.3A @120VAC, 0.2A @230VAC |
| Inrush Current | <15A peak @120VAC, <30A peak |
| Efficiency | 70+% |
| Output Ripple | 1% Max |
| Switching Frequency | 200kHz |
| Line Regulation | +/- 0.5% |
| Load Regulation | +/- 1% |
| Operating Temperature | -10C to +60 deg C |
| Storage Temperature | -20 to +85 deg C |
| Operating Humidity | -10C to +60 deg C |
| Size (LXWXH) | 85 x 55 x 33 (mm) |
| Weight | 4 oz |
| AC Connector | IEC-320 C6 |
| AC Power cord | Not included |
| Data IN / POE | RJ45 Shielded Socket |
| 80% Current Indicator | Power LED will change color |
| Surge Protection | Common Mode |
| Clamping Protection | 11V Data, 77.5V Power |
| Max Surge Discharge | 1200A (8/20uS) Power |
| Peak Pulse Current | 36A (10/1000uS Data) |
| Shunt Capacitance | <5pF data |
| Response Time | <1nS |
| Compliance | UL, EN55022 (CISPR22) class B, Meets CE |
| LAN Activity Indicator | Detects if LAN is connected to device |
| Remote Reset Capability | Supports Airmax Bullet,Rocket,Nano,Pico |
